1224 Automatic 4 Color Bottom Printing Printer Slotter Die Cutter Gluer Bundler Inline

Automatic bottom printing printer slotter die cutter gluer bundler inline consist of lead edge feeder,bottom printing unit, slotter unit,die cutter unit, folder gluer and bundler.which can make the carton directly from the corrugated cardboard. The whole line are technology,wit high speed and save much labor time.its very easy to operate no matter the worker has experience or not,the company will improve much more work affciency with this kind of machine.

Technologic parameter

Features

BOTTOM PRINTING PRINTER

1 Sun alike lead feeder makes feeding easily and stable,all the baffles adjusted by electric control

2 All the rollers undergo precise treatment,grinded and plated with rigid chrome and make balance rectification

3 All gears are made of 20CrMnTi,undergoes quenched and precised grinded for good printing, long life service and low running noise.

4 All the intervals adjusted by PLC and touch screen,easy to operate

5 Roll to roll transfer or vacuum transfer for operation at printing unit

6 Registering:+/-0.5mm

7 Doctor blade chamber or rubber roller ink distribution for option

8 Automatic zeroing among the unts of feeding,printing,slotting and die cutting

9 Automatic reposition after washing the printing plate during printing

10 Pre-creasing wheel,big creasing wheel and second creasing wheel at the slotting unit make the cardboard creasing better for folding

11 Steel cast slotting holder with linear guide rail and gear rail work together make slotting knife and cresing wheel move precise and smooth.

12 Single shaft slotting or double shaft slotting for option

FOLDER GLUER

1 Gluer speed sychorized with printer

2 Second creasing wheel make the creasing line better for folding

3 Upper and down belt extension can be adjusted as per different cardboard

4 Rectification structures avoid joint forming the fish tail

5 Inserting type collection or Drop type collection for option

6 Spray gluing system or wheel gluing system for option

BUNDLER(OPTION)

1 Connect with folder gluer

2 Can move in lateral direction

3 Pneumatic flapping structure make the carton tidy and easy to bundle

4 Special string mouth design, makes the string output smooth and never broken

5 Easy to maintain and operate

6 Bundling speed 15-20 bundles per minute.

Dongguang Kecheng Machinery Manufacturing Co.,Ltd.(K.C.), established in 1999,   Cangzhou Yongjin Internation Trading Co.,Ltd. (YJ)  is  the export company for Kecheng Machine, which is committed to supplying the good quality carton machines to the clients all over the world.

K. C. is specialized in various carton printing machinery to meet the diversified demand from the clients. Here are Top Printing Printer Gluer Inline ,Top Printing Printer Slotter Die Cutter, Bottom Printing Printer Gluer Inline,Bottom Printing Printer Slotter Die Cutter,Folder Gluer, Stitching Machine for option,no matter roller transfer or vacuum transfer, rubber roller with ceramic anilox roller or doctor blade chamber with ceramic anilox roller, any kinds of machine will get the quality guarantee before delivered out of our company.

K.C uses the techlogic management to make all the procedure go well, so we can respond to clients needs rapid under the support of the experienced and professional team. ONE STOP solution service makes the clieints business easier.Thanks to the integraty of the service, manufacturing productivity and product quality, K.C. is growing by building the solid partner with clients and suppliers.In order to make sure the machine quality, the manufacturing standard must be complied with our company standard which beyond the common industrial standards. All the  parts purchased are from the ourstanding and experienced supplier.

The goal we pursue is to be the trusted quality supplier in the carton machiney field for years and believe the following competitive strengths enable us to capitalize on the growth opportunities :

• Good quality machines with high performance and stability;

• Rapid repond to clients needs with precision and affciency

• Making sure all the parts qualified with long life service and secure;

• Manufacturing the easy-operation machine with capacity and utilization;

• Keeping the promises we make with honesty and sincerity.

K.C. will continue to focus on how to make the machine more technologic and efficient. We deeply undertand the world is changing so  fase, we also change our thought and improve our design and technology to make sure the the machine can increase the profit for the clients

Your success is our horner, expect to cooperate with you soon
